018F8701 COIL 220-230V 50HZ 10W terminal box

Оставить отзыв

По запросу

SKU

r_danfoss_018F8701

Ambient temperature: -40 - +80°C (NC valve), -40 - +55°C (NO valve). Permissible voltage variation: +10 - -15%, as double frequency coils: ±10%, a.c. coils for 220-230 / 380-400 V: +6 - -15%, as double frequency coils: +6 - -10%. Enclosure: IP 67. Terminal box: Leads are connected to terminal screws in the terminal box. The box is fitted with a Pg 13.5 screwed entry for 6 - 14 mm cable. Max. lead cross section: 2.5 mm2. Holding: 10 W/21 VA. Inrush: 44 VA

Цены со скидкой действуют при заказе от 7000 руб

Минимальная сумма заказа составляет 4000 руб

Подробности

Characteristic	Value
Type	BE230AS
Weight	0.308 Kg
Actuator size	13.5 mm
Ambient temperature range [°C]	-40 - 80 °C
Ambient temperature range [°F]	-40 - 175 °F
Approval	LLC CDC TYSK
Coil connection	CONNECTION BOX
Colour	Blue
EAN number	5702428024419
Enclosure rating	IP67
Frequency [Hz]	50 HZ
Identical product	018F6701
Pack format	Industrial pack
Power consumption [W]	10,0 W
Product Group	Solenoid valves
Product name	Solenoid coil
Quantity per pack format	50 pc
Spare part number	018F6176
Supply voltage [V a.c.]	220 - 230 V
Type designation	BE230AS
