032F1166

Оставить отзыв

По запросу

SKU

r_danfoss_032F1166

Refrigerants: R22/R407C, R404A/R507, R410A, R134a, R407A, R23. For other refrigerants, please contact Danfoss. Temperature of medium: –40 - +105°C (10 W / 12 W coil). Max. 130°C during defrosting. Min. opening differential pressure, EVR 2-3: 0.0 bar, EVR 6-22: 0.05 bar, EVR 25-32: 0.20 bar.

Цены со скидкой действуют при заказе от 7000 руб

Минимальная сумма заказа составляет 4000 руб

Подробности

Characteristic	Value
Type	EVR 10
Weight	0.361 Kg
Actuator system [mm]	13,5 mm
Ambient temperature [°C]	-40 - 80 °C
Ambient temperature range [°F]	-40 - 175 °F
Approval	C UL US LISTED, EAC, LLC CDC TYSK
Coil	No
Cv value [gal/min]	2,200 gpm US
Direction	Straightway
EAN number	5702422011750
Function	N C
Inlet connection type	SOLDER, ODF
Inlet size [in]	1/2 IN
Kv value [m³/h]	1,900 m3/h
Manual Operation	No
Max. Working Pressure [bar]	35,0 bar
Max. Working Pressure [psig]	500 psig
Max. OPD, 14 W a.c. [psi]	350 psi
Medium temperature range [°C]	-40 - 105 °C
Medium temperature range [°F]	-40 - 221 °F
Min. ODP [bar]	0,050 bar
Orifice size [mm]	10,00 mm
Outlet connection type	SOLDER, ODF
Outlet size [in]	1/2 IN
Pack format	Multi pack
Product Group	Solenoid valves
Product name	Solenoid valve
Quantity per pack format	12 pc
Refrigerant(s)	R134a
Refrigerant(s)	R22/R407C
Refrigerant(s)	R23
Refrigerant(s)	R404A/R507
Refrigerant(s)	R407A
Refrigerant(s)	R410A
Type designation	Solenoid valve, Solder
