060G2129

Оставить отзыв

По запросу

SKU

ia_danfoss_060G2129

AKS 33 are pressure transmitters that measure a pressure and convert the measured value to a standard 4-20 mA current signal. A robust design makes the AKS very suitable for application within a number of fields e.g. Air conditioning systems Refrigeration plant Process control Laboratories

Цены со скидкой действуют при заказе от 7000 руб

Минимальная сумма заказа составляет 4000 руб

Подробности

Characteristic	Value
Type	AKS 33
Weight	0.300 Kg
- common	BLACK
+ supply	BROWN
Accuracy, max. +/- FS [%]	0,80 %
Accuracy, typical +/- FS [%]	0,3 %
Adj. zero point and span	No
Ambient temperature [°C]	-40 - 85 °C
Ambient temperature range [°F]	-40 - 185 °F
Approval	ATEX, C UR, CSA, GOST POCC
Approval comments	ATEX Ex nA IIA T3 Gc
Approval standard	6967179
Approval standard	E227388
Approval standard	E31024
Cable length [in]	79,00 in
Cable length [m]	2,00 m
Compensated temp. range [°C]	-30 - 40 °C
Compensated temp. range [°F]	-22 - 104 °F
EAN	5702422067436
Electrical conn. comments	Screened
Electrical connection type	Cable
Enclosure rating	IP67
Flush diaphragm	No
Intrinsically safe	No
Medium temperature range [°C]	-40 - 85 °C
Medium temperature range [°F]	-40 - 185 °F
Non-linearity BFSL ±FS [%]	0,20 %
Output signal type	4 - 20 mA
Overload pressure max. [bar]	33,0 bar
Packing format	Multi pack
Pressure connection standard	ANSI/ASME B1.20.1
Pressure connection type	NPT - 1/4-18 Male
Pressure range [bar]	-1,00 - 9,00 bar
Pressure range [psi]	-14,50 - 130,53 psi
Pressure unit reference	Gauge (relative)
Pulse-snubber	No
Quantity per packing format	8 PC
Response time max. [ms]	4 ms
Specification key	AKS 33
Supply voltage [V] d.c.	10,00 - 30,00 V
